Creator design reference for XT60 Connector Shell — Female; included printed parts are specified in the listing.Design reference photo

Creator photo; included parts are listed below. Accessories not included.

Electronics & racks / Parts for your next project

XT60 Connector Shell — Female

3D printed in PETG for covering the rear of a compatible female XT60 connector.

$27.99 CAD

Shipping within Canada is included in the listed price. Applicable taxes are calculated at checkout. Secure checkout for Canadian shipping addresses. Choose your quantity on Stripe. Shipping to the U.S.? Contact us for a shipping quote before ordering. U.S. shipping is an additional charge.

Check fit before ordering ↓

A closer look

3D printed in PETG for covering the rear of a compatible female XT60 connector. Includes one female shell comprising the XT and XTS printed halves. Electronics, batteries, metal contacts, fasteners, accessories shown and installation are not included.

Check the fit

Start with these details so you can choose the right part for your setup.

  • Confirm your board, connector or rack dimensions and mounting-hole pattern before ordering.

What’s included

  • One female shell comprising the XT and XTS printed halves.
  • Electronics, batteries, metal contacts, fasteners, accessories shown and installation are not included.

Finish the rear of a compatible female XT60 connector

The two printed halves form a rear shell for a compatible female XT60 connector, giving the cable end a more defined external shape within a custom project. It is useful when you are planning how the connection will be handled and where the wires will leave it. Consider the shell early in the cable build so its assembly order can be checked before the wires and neighbouring components restrict access. The connector remains a separately supplied electrical component; this shell provides only the printed covering pieces.

Match the connector and completed wire exit

Compare the exact female XT60 body, rear shoulders and cable exit with the XT and XTS halves. The parts are listed at approximately 19.5 × 7.05 × 35 mm and 19.5 × 6.05 × 35 mm individually. These are not internal clearances or an assembled shell thickness that can be obtained simply by adding the smaller dimensions. Include existing insulation, wire sleeving and any termination covering in the fit check. A connector that appears correct from the front can have a rear profile that interferes with the shell.

Preserve normal connector handling

Trial-fit the halves with the electrical assembly disconnected. They should meet without pinching wires, displacing insulation or preventing the connector from mating fully. Check the grip area used when joining and separating the connector, and leave room for the cable to turn naturally toward the rest of the project. If the connector sits near an enclosure wall, compare the complete assembled shell with that wall and the mating plug. Plan required cable support separately; no rated strain-relief function is stated for the printed shell.

Inspect the shell whenever the cable is serviced

Handle the connection by its appropriate connector body rather than using the wires to pull it apart. Look for gaps, cracking or changes in fit at the printed halves, and check the wire exit for rubbing. Remove dust with the assembly disconnected, keeping liquids and debris away from contacts. The shell does not supply an electrical, sealing or fire-containment rating, so retain the insulation and other provisions required by the project. If the connector or wire arrangement changes, repeat the complete fit trial instead of assuming the existing shell will still close correctly.

Product questions

What does the listed price include?

One female shell comprising the XT and XTS printed halves. Shipping within Canada is included in the listed price. Applicable taxes are calculated at checkout. Electronics, batteries, metal contacts, fasteners, accessories shown and installation are not included.

Will this match everything shown in the photo?

The creator photo is a design reference and may show other variants, quantities or accessories. The included-parts list describes exactly what this listing supplies.

Is this the connector or a cover for it?

It is a rear cover made from the XT and XTS printed halves. The female XT60 connector, metal contacts and wiring are supplied separately.

Will the shell fit a male XT60 connector?

This listing is for a female-shell design. A male connector needs its own verified fit; similar front shapes do not establish compatible rear dimensions.

Can I use the shell in place of termination insulation?

No electrical protection rating is specified. Keep the insulation and termination provisions required by the project, then check that the shell fits around that completed arrangement.

Original design: 万年情 — xt60外壳. MakerWorld model 757261. Original design
