Battery Cell Spacing Bracket

3D printed in PETG for positioning compatible cells in a custom project.

$29.99 CAD

Shipping within Canada is included in the listed price. Applicable taxes are calculated at checkout. Secure checkout for Canadian shipping addresses. Choose your quantity on Stripe. Shipping to the U.S.? Contact us for a shipping quote before ordering. U.S. shipping is an additional charge.

Check fit before ordering ↓

A closer look

3D printed in PETG for positioning compatible cells in a custom project. Includes one printed battery-cell spacing bracket in the listed configuration. Electronics, batteries, metal contacts, fasteners, accessories shown and installation are not included. Printed housing only; no electrical function is supplied.

Check the fit

Start with these details so you can choose the right part for your setup.

  • Confirm your board, connector or rack dimensions and mounting-hole pattern before ordering.

What’s included

  • One printed battery-cell spacing bracket in the listed configuration.
  • Electronics, batteries, metal contacts, fasteners, accessories shown and installation are not included.

Lay out cells consistently within a custom project

A spacing bracket helps define the physical relationship between compatible cells while you plan a custom assembly. That can be useful when comparing an enclosure layout, keeping a repeated arrangement orderly or checking how other parts will sit around the cells. Start with a drawing of the intended configuration and identify where each cell, connection and support belongs. The printed bracket supplies a positioning geometry; the complete project still needs its own suitable mechanical retention and electrical design. Use the bracket as one part of that plan rather than treating it as a completed battery assembly.

Check the cell profile and the full surrounding space

The approximate 81.5 × 101.5 × 6 mm measurements describe the bracket's individual outer dimensions. They do not state the diameter of the cell openings, the number of cells appropriate to your project or the completed pack size. Compare the listed configuration with the actual cells and any sleeves, contact pieces or other surrounding components. Include the space needed for wiring and for components that extend above or below the bracket. A cell that matches a nominal family name can still need a different fit when additional terminal or protective features are present.

Use the bracket during layout verification

Check the mechanical arrangement before making electrical connections. Use dimensional references or appropriately handled unconnected components to confirm spacing, orientation and enclosure clearance. The bracket should position parts without damaging cell wrappers or forcing a mismatched cell into an opening. Plan how the assembly will be retained independently of its electrical connections, so wires or conductive links are not asked to hold the cells in place. Keep the intended polarity arrangement clear in your project records, and follow the requirements of the cells and electrical components you select.

Keep electrical functions separate from positioning

The bracket has no supplied electrical function and does not establish charging, balancing, protection, insulation or thermal performance for a battery project. Those requirements need appropriate components and competent integration. Retain access for inspection wherever your design requires it, and reassess fit if you change the cell type or surrounding materials. Remove loose debris before assembly and check the printed part for cracks or distortion. If a cell wrapper or bracket is damaged during a trial fit, stop and resolve the fit issue rather than forcing the assembly together.

Product questions

What does the listed price include?

One printed battery-cell spacing bracket in the listed configuration. Shipping within Canada is included in the listed price. Applicable taxes are calculated at checkout. Electronics, batteries, metal contacts, fasteners, accessories shown and installation are not included.

Will this match everything shown in the photo?

The creator photo is a design reference and may show other variants, quantities or accessories. The included-parts list describes exactly what this listing supplies.

Does this bracket make a ready-to-use battery pack?

No. It is a printed positioning part. The cells, connections, retention, protection and all other electrical provisions must be designed and supplied separately.

Can I determine cell diameter from the outside dimensions?

No. The outer bracket dimensions do not define its openings. Compare the actual listed configuration and mating geometry with your exact cells before ordering.

Should the bracket carry the assembly through its wires?

No. Plan appropriate mechanical retention for the complete project so that electrical connections are not used as supports. The bracket's stated function is positioning compatible cells.
