Creator design reference for AA Battery Compartment Shell — Single Cell; included printed parts are specified in the listing.Design reference photo

Creator photo; included parts are listed below. Accessories not included.

Electronics & racks / Parts for your next project

AA Battery Compartment Shell — Single Cell

3D printed in PETG for housing components of a custom AA battery project.

$27.99 CAD

Shipping within Canada is included in the listed price. Applicable taxes are calculated at checkout. Secure checkout for Canadian shipping addresses. Choose your quantity on Stripe. Shipping to the U.S.? Contact us for a shipping quote before ordering. U.S. shipping is an additional charge.

Check fit before ordering ↓

A closer look

3D printed in PETG for housing components of a custom AA battery project. Includes one single-AA-cell open compartment shell; metal contacts excluded. Electronics, batteries, metal contacts, fasteners, accessories shown and installation are not included. Printed housing only; no electrical function is supplied.

Check the fit

Start with these details so you can choose the right part for your setup.

  • Confirm your board, connector or rack dimensions and mounting-hole pattern before ordering.

What’s included

  • One single-AA-cell open compartment shell; metal contacts excluded.
  • Electronics, batteries, metal contacts, fasteners, accessories shown and installation are not included.

Plan an accessible location for one AA cell

This open compartment shell is useful for developing the physical layout of a custom project that uses a single AA cell. Start by deciding how the cell will be inserted and removed once the rest of the project is assembled. A location that is easy to reach on the bench may become awkward behind a circuit board or inside a finished case. Keeping the cell position visible and accessible can simplify later inspection and replacement. The open form should be considered alongside the rest of your enclosure design, including how the cell will remain appropriately contained. The shell supplies the printed physical compartment without determining the project's electrical behaviour.

Check the cell, contacts, and replacement movement

The approximately 17.9 × 59.4 × 15.7 mm measurements describe the printed part overall. Allow additional room for the actual cell, separately selected metal contacts, wire routing, and the movement needed to remove the cell. Compare the contact arrangement with both ends of the compartment before making a tight outer enclosure. If a separate cover is planned, check that it can close without pressing excessively on the cell or shifting a contact. Consider how you will identify polarity on the finished project. A clear marking and reachable compartment are more useful than a compact layout that makes every cell change a disassembly task.

Keep the housing role distinct during assembly

Fit and inspect the mechanical arrangement with the cell removed. Check that separately supplied contacts are retained appropriately and that wires cannot be trapped under the cell or between the shell and another part. Follow the requirements of the cell and electronics used in your project; the PETG shell does not provide contacts, charging control, or a particular output voltage. When replacing a cell, inspect the compartment for debris and look at the condition of the contact arrangement before reloading it. Correct a loose or distorted fit rather than forcing the cell into place. Keep loose metal parts away from the compartment while the project is open for service.

Product questions

What does the listed price include?

One single-AA-cell open compartment shell; metal contacts excluded. Shipping within Canada is included in the listed price. Applicable taxes are calculated at checkout. Electronics, batteries, metal contacts, fasteners, accessories shown and installation are not included.

Will this match everything shown in the photo?

The creator photo is a design reference and may show other variants, quantities or accessories. The included-parts list describes exactly what this listing supplies.

Is this a complete wired battery holder?

No. It is an open printed compartment shell for a single AA-cell project. The electrical contacts and other circuit components must be selected and provided separately for the intended application.

Can I use it as a closed storage case?

The supplied part is described as open and does not establish a transport closure. For carrying spare cells, use an arrangement intended to contain them and keep their terminals appropriately separated.

How much extra enclosure space should I allow?

Check the actual completed arrangement rather than applying a fixed allowance. Include the cell ends, chosen contacts, wire exits, any separate cover, and enough access to remove the cell without levering against electronics.

Original design: DESK3DSOLUTION — Universal Battery Compartment Shells (AA/AAA). MakerWorld model 2431567. Original design
